PERMABOND ET505 MIXING RATIO 1:1 SLOW SET 60 - 120 MIN TOUGH, MULTI-PURPOSE TWO COMPONENT EPOXY ADHESIVE CARTRIDGES & ACCESSORIES

SKU: PBND_ET505_050ML

Need Datasheets? Need Accessories?

• Click Here to visit our Datasheet Server (TDS, SDS, Fact Sheets, Selector Guides, etc)
• Check out Popular Accessories below by scrolling down just a bit on this page.
Size
Select the Kit needed
Regular price $ 19.99 USD
($ 0.39 USD per Milliliter)
Currently Out of Stock Call for ETA

Volume Discounts

6 units @ $ 19.00 ea, saving 5%

12 units @ $ 18.40 ea, saving 8%

36 units @ $ 18.00 ea, saving 10%

Add Mixing Nozzles for the 50ml & 41.5ml "Gray-Cap" Cartridges
Add Mixing Nozzles for the Larger Cartridges (200ml to 1500ml)
Add Dispensers for 50ml & Similar Sized Smaller Cartridges
_io_Add Dispensers for 400ml Cartridges
Add Bond Performance Enhancers
Add Needed Documents
Currently Out of Stock Place Order and Call for ETA

Want a Delivery Estimate?

SKU

  • SKU PBND_ET505_050ML

PERMABOND ET505 is a two-part, 1:1 mixable epoxy adhesive. ET505 is a semi-flexible toughened epoxy adhesive with good adhesion to a variety of substrates such as wood, metal, ceramics and some plastics and composites. Permabond ET505 forms tough bonds providing high peel resistance and high shear strength. The extended work life of this product allows for adjustment and makes it more suitable for larger applications.

Features & Benefits

  • Adhesion to a wide variety of substrates
  • Full cure at room temperature
  • Set time 60 - 120 min
  • Easy to apply
  • High shear and peel strength
  • Good impact strength
  • Good chemical resistance

Available Accessories

  • Mixing nozzles
  • Caulking gun adaptor
  • Dispensing guns

    Physical Properties of Uncured Adhesive

    ET500A

    ET500B

    Chemical composition

    Epoxy Resin

    Amine Hardener

    Appearance

    Colourless

    Amber

    Viscosity @ 25°C

    14,000-28,000 mPa.s (cP)

    10,000-25,000 mPa.s (cP)

    Specific gravity

    1.1

    1.0

    Typical Curing Properties

    Mix ratio by volume

    1:1

    Maximum gap fill

    2 mm 0.08 in

    Usable / pot life @23°C

    1-2 hours

    Handling time @23°C

    3-5 hours

    Working strength @23°C

    24 hours

    Full cure @23°C

    72 hours
