PLEXUS MA8120 GB - Metals, Zinc-Treated, Galvanized Metals, Hot-Dipped Metals, Nylons, and Plastics MMA Glue Slow 20-Min Set Toughened Low-Odor Marine Optimized
Need Datasheets?
Click Here to visit our Datasheet Server (TDS, SDS, Fact Sheets, Selector Guides, etc)
Regular price
$43.00 CAD
Call for ETA
An advanced Metal, Nylon, and Hard Plastics bonding low halogen two-part methacrylate structural adhesive. Plexus MA8120 GB is designed for the structural bonding of most all popular Metals, including Hot Dipped G90 and G60, All Nylon types, and most hard plastics, as well as composites and laminate assemblies. It is Reinforced with Glass-Microbeads (GB stands for Glass Beads) to enforce a minimum bond gap/width and to enhance the strength and toughness of the structural glue.
It has a rather slow-set time of 18-25 minutes, with handling streanth around 60-90 minutes
Compatible Surfaces
- Raw metals Aluminum, Stainless Steel, Raw Steel, etc.
- Coated metals Hot Dipped Galvanized, Electrogalvanized, Powdercoated or E-coated Metals
- Optimized for Direct Nylon bonding (all nylon types, Nylon-6, Nylon-12, etc)
- Thermoplastics ABS/ ABS Blends, Acrylics, Polyamides/Nylons, PBT, Polycarbonate, Rigid PVC, TPU
- Composites DCPD, FRP, Gelcoat, Phenolics, Epoxy Based Composites, RIM
Key Features:
- All popular metals, Galvanized Metals, Hot-Dipped Metals,
- All Nylon types (Nylon-6, Nylon 12, etc), and all hard plastics Plastics like ABS, PVC, PC, Acrylic, etc (no HDPE, LDPE, or Polyolefins)
- Most thermoplastics, composites and laminates
- Contains Glass Bead (GB) microspheres for minimum bondline enforcement.
- Has exceptional strength and elongation which allows for bonding of dissimilar materials
- Excellent fatigue resistance, impact resistance and toughness
- Easy to use 1:1 ratio product
- 18-25 Minute Working time, considered a slower-setting glue
- Low odor formula
- Excellent environment resistance to salt spray and other environmental factors
Back-Ups, Substitutes, and Similar Formulas:
These formulas are all similar and can be substitutes depending on the use case:
Plexus MA8105GB (5-Minute Set) Maven MMA8105 GB (5-Minute Set) Plexus MA8110GB (10-Minute Set) Maven MMA8110 GB (10-Minute Set) Plexus MA8120GB (20-Minute Set) Maven MMA8120 GB (20-Minute Set)
Properties
- Color: Gray
- Mix Ratio: 1:1
- Contains Glass Bead microspheres for minimum bondline enforcement.
- Shear Strength: 1,800 – 2,400 psi (12.4 – 16.5 MPa)
- Adhesive: 40,000 – 70,000 cP
- Activator: 40,000 – 70,000 cP
- Working Time Min: 18 minutes
- Working Time Max: 22 minutes
- Fixture Time Min: 70 minutes
- Fixture Time Max: 90 minutes
- Tensile Strength Min: 2,500 psi (17.2 MPa)
- Tensile Strength Max: 3,000 psi (20.6 MPa)
- Tensile Elongation Min: 45 %
- Tensile Elongation Max: 65 %
