Permabond 802 Cyanoacrylate high viscosity, fast curing, surface insensitive adhesive

Product Name

Permabond 802 Cyanoacrylate high viscosity, fast curing, surface insensitive adhesive

Brief Description

Permabond 802 is a modified ethyl cyanoacrylate adhesive characterized by its fast curing properties, surface insensitivity, and high-temperature resistance. It is designed to form strong bonds rapidly on a wide variety of materials without the need for mixing or heat curing.

Popular Applications & Uses

- Bonding metals, ceramics, plastics, elastomers, wood, fabric, and leather.- Ideal for high-speed production lines and assembly operations.- Used in model and jewelry assembly.- Suitable for wire tacking and strain relief in electronics, including speakers, motors, and computer boards.- Employed in bonding components for mobile phones.- Can withstand brief periods of higher temperatures, making it suitable for processes like paint baking and wave soldering, provided the joint is not unduly stressed.

Industries that Commonly Use It

- General Manufacturing- LED/Electronics (for bonding components and wire tacking)- Metal Fabrication (due to strong adhesion to metals)- Plastic Fabrication (for bonding various plastics)- Automotive Service/Repair (for general bonding applications in manufacturing and repair)- Artist, Artisan (for model and jewelry assembly)- Industrial Supply (as a high-performance industrial adhesive)- Distributers & Resellers (as it is sold through distributors like Perigee Direct)

Special and Unique Features

- High temperature resistance, capable of continuous operation up to 160°C (320°F) and brief exposures to higher temperatures.- Rapid curing and fast setting, achieving handling strength in seconds.- Surface insensitive, allowing for consistent and reliable curing even on acidic or porous surfaces like wood and dechromated metals.- Ease of use, requiring no mixing or external heat cure.- 100% reactive formulation, containing no solvents.- Cures by reacting with trace amounts of moisture present on the substrate surfaces.

Key Properties

- Chemical Composition: Ethyl cyanoacrylate- Appearance: Colourless liquid- Viscosity @ 25°C: 90-110 mPa.s (cP)- Specific Gravity: 1.1- Fixture/Handling Time (e.g., Steel, Buna N Rubber, Phenolic): 10-15 seconds- Full Strength: 24 hours- Maximum Gap Fill: 0.15mm (0.006")- Shear Strength (Steel): 19-23 N/mm² (2800-3300 psi)- Hardness (Shore D): 85- Operating Temperature Range: -55°C to 160°C (-65°F to 320°F)- Dielectric Strength: 25kV/mm- Solubility: Hardens in contact with water, insoluble in water.

Surface Compatibility

- Rubber- Metals (e.g., steel, aluminum, copper)- Plastics (e.g., ABS, PVC, Polycarbonate)- Ceramics- Elastomers- Wood- Fabric- Leather- Other porous substrates- Acidic surfaces

Known backups / known substitutes

- Permabond 798: A high viscosity, fast-set cyanoacrylate adhesive also suitable for various substrates.- Permabond 820: Another high-temperature resistant cyanoacrylate adhesive, with resistance up to 200°C.- Permabond 792: A high-temperature, surface-insensitive, fast-curing cyanoacrylate adhesive.- Loctite 435: A low viscosity cyanoacrylate with excellent peel strength and flexibility, bonding a wide range of materials.- Loctite 411: A toughened, high viscosity cyanoacrylate adhesive known for its versatility.- Permabond 910: A general-purpose cyanoacrylate adhesive.

Comparison Note

The user's prompt and the provided URL (https://www.perigeedirect.com/products/permabond-802-cyanoacrylate-high-viscosity-fast-curing-surface-insensitive-adhesive) describe Permabond 802 as a "high viscosity" adhesive. However, Permabond's official technical data sheets and product descriptions from various distributors consistently classify Permabond 802 as a "low viscosity" modified ethyl cyanoacrylate, typically with a viscosity range of 90-110 mPa.s (cP) at 25°C. High viscosity cyanoacrylates are generally thicker and often preferred for gap filling or applications on vertical surfaces.
