Leister 162.799 Fusion 1 Compact Extrusion Welder

Product Name

Leister 162.799 Fusion 1 Compact Extrusion Welder

Brief Description

The Leister Fusion 1 is an ultra-compact and lightweight handheld extrusion welder specifically engineered for plastic welding in confined and hard-to-reach spaces. It features an integrated air guide and a removable handle, offering exceptional maneuverability and flexibility for various plastic fabrication and repair tasks.

Popular Applications & Uses

- Welding connection nozzles- Fabricating small tanks and pipe junctions- General plastic repairs- Boat construction and repair- Canal and pond waterproofing- Landfill and mining membrane welding- Container construction- Roofing applications- Technical textiles and industrial fabrics- Geo and civil engineering projects

Industries that Commonly Use It

- Plastic Fabrication- Construction/Building Services (for waterproofing, roofing, civil engineering)- Marine (for boat construction and repair)- Pool/Spa/Plumbing (for pond waterproofing and similar applications)- Tarp, Fabric, Awning Manufacturing (for technical textiles and industrial fabrics)- General Manufacturing (for various plastic repairs and fabrication)

Special and Unique Features

- Compact and slimline design for increased maneuverability in tight spaces- Integrated LED light to illuminate the welding area- Double-sided welding rod intake for enhanced flexibility- Removable handle allows for comfortable one-handed welding- Automatically controlled air temperature (closed-loop system) for precise and reliable welding- Digital temperature display for easy monitoring and adjustment- Mounting point for a tool balancer to reduce fatigue during extended use- Motor start-up protection to prevent damage from cold starts- 360º adjustable welding shoe for versatile application

Key Properties

- Welding materials: PE (Polyethylene), PP (Polypropylene), HDPE, LDPE, LLDPE, FPO, TPO- Welding rod diameter: Ø 3–4 mm (0.12–0.16 in)- Material output (HDPE): 0.2 - 0.8 kg/h (depending on rod size and conditions)- Recommended weldable sheet/membrane thickness: 5 - 12 mm- Power: 1450 W (120V) or 1200 W (230V)- Weight: 3.4 kg (7.5 lbs) without power cord- Air temperature control: Closed loop- Screw heating: Air heated

Surface Compatibility

The Leister Fusion 1 is compatible with a range of thermoplastic materials, primarily Polyethylene (PE) and Polypropylene (PP). This includes High-Density Polyethylene (HDPE), Low-Density Polyethylene (LDPE), Linear Low-Density Polyethylene (LLDPE), Flexible Polyolefin (FPO), and Thermoplastic Polyolefin (TPO).

Known backups / known substitutes

- Leister FUSION 2 Extrusion Welder- Leister WELDPLAST S1 Extrusion Welder- Leister WELDPLAST S2 Extrusion Welder- Other compact plastic extrusion welders from various manufacturers

Comparison Note

The Leister Fusion 1 distinguishes itself from larger extrusion welders by its exceptionally compact and slim design, making it the smallest and most agile in the Leister range. This design is particularly advantageous for intricate welding tasks and applications in tight or restricted spaces where larger tools would be impractical. Unlike some other models in the Leister Fusion series, the Fusion 1 features a closed-loop air temperature control system, ensuring precise and consistent welding temperatures for greater process reliability.
