MedMix (Sulzer) MCH 08-24T Mixing Nozzle-Round Helix Bell Style - for 1:1 & 2:1 ratio 200ml, 400ml, 600ml, 1500ml 2-Part cartridges

In stock
SKU: SULZER_MIXER MCH 08-24T 102424_001
Which Multi-Pack Count?
Regular price $3.00 CAD
4205 units available
4205 units are available

MedMix (Sulzer) MCH 08-24T Mixing Nozzle-Round Helix Bell Style - for 1:1 & 2:1 ratio 200ml, 400ml, 600ml and 1500ml universal Bell-Style mixing nozzles (10-inch 24-element Mixing Nozzles) for all standard C-System 200ml, 400ml, 600ml and 1500ml 2-Part epoxy and adhesive cartridges.

Specifications:

  • 8mm inner diameter helix, round nozzle style
  • 10-inch nozzle length
  • 24-element count (24 mixing cycles for the material)
  • Bell Style inlet fitting
  • For all Medium and Thicker viscosities, 80,000 cP or higher
  • Recommended for Epoxy, Silicone, Urethane, Acrylic, Polyesters
  • Not recommended for Urethanes and Polyturethanes

Works perfectly with all major branded adhesives that use the larger (C-System) adhesive cartridges, 200ml, 400ml, 600ml, 1500ml, and related cartridge types. Works with all standard C-System cartridges by Sulzer MixPac, and 2k cartridges by Nordson EFD. Each Pack includes the same number of mixing nozzles plus the related inner/inside mixing assembly

The MedMix (Sulzer) MCH 08-24T Mixing Nozzle-Round Helix Bell Style are used to dispense 2-part adhesives from 200ml, 400ml, 600ml and 1500ml C-System plastic cartridges, and works with both 1:1 and 2:1 ratio formulas.

This mixer is connected with a bell outlet and has a stepped tip that can be cut to adjust the amount of adhesive being dispensed.
