SynthoGlass Pipe Repair Kits
Need Datasheets? Need Accessories?
• Click Here to visit our Datasheet Server (TDS, SDS, Fact Sheets, Selector Guides, etc)• Check out Popular Accessories below by scrolling down just a bit on this page.
Regular price
$68.00 CAD
12 units available
Syntho-Glass® is the original patented fiberglass repair wrap with resin system, designed for fast and dependable pipe reinforcement. It is pre-impregnated and activated by either fresh or saltwater, so it’s ready to use straight out of its hermetically sealed foil pouch, without any measuring or mixing required.
When used with the right primary sealant, Syntho-Glass® can repair and reinforce virtually any pipe in minutes. It not only restores the pipe to its original pressure rating but can even make the repaired section stronger than before, while helping reduce costly downtime and saving on replacement parts and labor.
Because it cures quickly, within just 30 minutes at 75°F (24°C), Syntho-Glass® is ideal for emergency leak repair. It works across a wide range of materials, including copper, steel, stainless steel, PVC, FRP, clay, concrete, and rubber pipes. Plus, it is nontoxic, noncombustible, and odorless, so it’s inherently safe for use in demanding environments.
Each Syntho-Glass® Pipe Repair Kit includes all the components needed for installation. And since it arrives sealed, portable, and immediately ready to apply, it ensures simple, effective, and long-lasting repairs wherever and whenever you need them.
|
Part Number |
Wrap Size Width (in) & Length (ft) |
Pipe Size coverage by wrap |
| SG205 | 2 in x 5 ft | ½ to 1 in |
| SG309 | 3 in x 9 ft | 1 ¼ to 2 in |
| SG415 | 4 in x 15 ft | 2 ½ to 4 in |
| SG420 | 4 in x 20 ft | 4 to 6 in |
| SG430 | 4 in x 30 ft | 4 to 6 in |
| SG450 | 4 in x 50 ft | 4 to 8 in |
| SG830 | 8 in x 30 ft | 12 to 16 in |
| SG850 | 8 in x 50 ft | 12 to 16 in |
Two Kit Grades:
- General Purpose (This page) - Slightly less flexible, but also less expensive.
- Industrial Grade (click here for the Industrial page)- Slightly more flexible fiberglass fabric, easier to wrap, and conforms to military specification NSN# 5330-01-242-6187
Typical Applications
- Impact Protection
- Emergency Repair
- Corroded Pipes
- Irregular pipe fittings
- Force Mains and gravity lines
- Joint and Tee repair
- Underwater repair and splash zone
Benefits
- Ready-to-use pipe repair wrap for fast application
- No mixing, mess, or special tools required
- Environmentally safe and contains no VOCs
- Provides simple, effective, and durable restoration
- Fully cures in minutes for quick return to service
Features
- Supplied as a complete kit with all necessary materials
- Quick and easy installation for emergency leak repair
- Excellent adhesion to metals, plastics, and other substrates
- Good chemical resistance range for harsh environments
Physical Properties
- VOCs: None
- Set Time: 30 Minutes at 75°F (24°C)
- Resin Type: Water-activated polyurethane
- Resin Application: Pre-impregnated
- Service Temperature: -50° to 250°F (-45° to 121°C)
- Application Temperature: 32° to 150°F (0° to 65°C)
- Pressure once cured w/primary sealant: Max 300 psi (20.6 bar)
Working Time
- 5 Minutes at 75°F (24°C)
Shelf Life
-
24 months with recommended storage
Storage Conditions
- Store in original container protected from direct sunlight in a dry, cool and well-ventilated area, away from incompatible materials, food and drink. Storage at temperature between 64°F and 86°F. Keep away from humidity and water. Keep container tightly closed and sealed until ready for use.
