Cox PPM 600X Manual 2-Part Adhesive Dispenser for 1:1, 2:1, and 4:1 ratio 1200ml, 900ml, 750ml Cartridge Sizes (aka M600X)

SKU: COX_DM2C 1200-01-R25-003

Need Datasheets? Need Accessories?

• Click Here to visit our Datasheet Server (TDS, SDS, Fact Sheets, Selector Guides, etc)
• Check out Popular Accessories below by scrolling down just a bit on this page.
Size
$151.00 CAD
Currently Out of Stock Call for ETA

Volume Discounts

5 units @ $143.45 ea, saving 5%

10 units @ $135.90 ea, saving 10%

20 units @ $128.35 ea, saving 15%

Currently Out of Stock Place Order and Call for ETA

Want a Delivery Estimate?

SKU

  • SKU COX_DM2C 1200-01-R25-003
Description Need Datasheets?
Cox PPM 600X Manual 2-Part Adhesive Dispenser for 1:1, 2:1, and 4:1 ratio 1200ml, 900ml, 750ml Cartridge Sizes (aka M600X)
Also Known As Part Numbers:
159301 DM2C 1200-01-R25-003 M600X/1 DM2 M600X-01
159302 DM2C 1200-02-R25-003 M600X/2 DM2 M600X-02
159303 DM2C 1200-04-R25-003 M600X/4 DM2 M600X-04
COX is among the global leaders in quality caulk and adhesive applicators. Their catalog covers a wide range of manual, pneumatic and battery powered models, all of which are well-stocked in the USA to ship out to any customer in the US or Canada.
All products in the COX line are manufactured by COX at facilities in Haslett, Michigan or Newbury, England. Manufacturing processes adhere to rigid quality management, offering reliability and durability.
Every COX product is warranted against defects in material and workmanship for a period of one year from the date of purchase and we have a full parts and service department to provide continued technical assistance and support.
  • Works with the large 1200ml (1:1), 900ml (2:1), and 750ml (4:1) ratio empty cartridges
  • Steel Frame and Catch Plate
  • 25:1 Mechanical Advantage (multiplies hand strength 26 times)
  • Maximum force 1011 lbf
  • Top Loading Frame – For Fast & Accurate Cartridge Setup
  • All Components can be ordered - Replaceable Parts

FEATURES

  • Support Discs for Secure Cartridge Fit
  • Sintered Steel Catch Plate
  • Wear Compensation Device

SPECIFICATIONS

  • Cartridge Capacity: 675 mL / 23 oz, 750 mL / 26 oz,

900 mL / 31.6 oz, 1200 mL / 42 oz

  • Cartridge Ratio: 1:1, 2:1, 4:1, 8:1 (must specify)
  • Mechanical Advantage Ratio: 25:1
  • Weight: 1 kg / 4.8 lbs
  • Frame Length: 230 mm / 1 in
  • Maximum Force: 5 kN / 1011 lbf
  • Handle Material: Epoxy Coated Aluminum
  • Frame Material: Epoxy Coated Steel
  • Viscosity: High
